Short description
Stainless Steel High Pressure 20CV Series Check Valve, 4.70 Cv, 3/4 in. MPF Part #: 20CV-MPF12-V-316
PT Jacesti Antamani — official sole agent of Hikelok for Indonesia.
Product details
| Attribute | 20CV Series Check Valve |
|---|---|
| Body Material | 316 Stainless Steel |
| Connection 1 Size | 3/4 in. |
| Connection 1 Type | MPF |
| Connection 2 Size | 3/4 in. |
| Connection 2 Type | MPF |
| Seat Material | Fluorocarbon FKM |
| CV Maximum | 4.70 |
| Orifice | 0.516 in. 13.11 mm |
| Temperature Rating | 0°F to 400°F (-17.8°C to 204°C) |
| Working Pressure Rating | Max 20,000 psig (1379 bar) |
| Testing | hydraulic test |
| Cleaning Process | Standard Cleaning and Packaging (CP-01) |
