Short description
Stainless Steel 20NV Series Needle Valve, 0.31 Cv, 1/4 in. MPF, Straight Part #: 20NV-MPF4-316
PT Jacesti Antamani — official sole agent of Hikelok for Indonesia.
Product details
| Attribute | Ultra-high Pressure Needle Valves |
|---|---|
| Body Material | 316 Stainless Steel |
| Connection 1 Size | 1/4 in. |
| Connection 1 Type | MPF |
| Connection 2 Size | 1/4 in. |
| Connection 2 Type | MPF |
| Stem Tips | Vee |
| Packing | PTFE |
| Flow Patterns | Straight |
| CV Maximum | 0.31 |
| Orifice | 0.125 in. /3.18 mm |
| Maximum Working Pressure | 20000 psig (1379 bar) |
| Working Temperature | -100℉ to 450℉ (-73℃ to 232℃ ) |
