Deskripsi singkat
Stainless Steel High-Flow Bellows-Sealed Valves, 5.0 Cv, 1/2 in. Fractional Tube Butt Weld Part #: BBS1-FFBW8-M4-M4-10-NC-316L-LD
PT Jacesti Antamani — one solo agent Hikelok untuk Indonesia.
Detail produk
| Attribute | Bellows- Sealed Valve |
|---|---|
| Body Material | 316L Stainless Steel |
| Connection 1 Size | 1/2 in. |
| Connection 1 Type | Fractional Tube Butt Weld |
| Connection 2 Size | 1/2 in. |
| Connection 2 Type | Fractional Tube Butt Weld |
| Tip Type | PCTFE |
| CV Maximum | 5 |
| Seat- Orifice | 0.5 in /12.7 mm |
| Upstream Purge Valve & Purge Port | None |
| Valve& Port Size | 1/4 Male GFS Fitting |
| Downstream Purge Valve & Purge Port | None |
| Surface Finish | 0.25Ra max-EP |
| Handle Wheel | Spring Return, Normally Closed |
| Lock | Handle Lockout Clear Clam Shell |
