Deskripsi singkat
Stainless Steel DV5 Series Diaphragm Valves, 0.20 Cv, 1/4 in. Tube Butt Weld Part #: DV5-FBW4-H-316
PT Jacesti Antamani — one solo agent Hikelok untuk Indonesia.
Detail produk
| Attribute | Diaphragm Valves |
|---|---|
| Body Material | 316 Stainless Steel |
| Connection 1 Size | 1/4 in. |
| Connection 1 Type | Tube Butt Weld |
| Connection 2 Size | 1/4 in. |
| Connection 2 Type | Tube Butt Weld |
| Pressure Type | High- Pressure Valves |
| Orifice | 0.16 in. /4.1 mm |
| CV Maximum | 0.20 |
| Handle Color | Blue |
| Flow Path | Straight |
| Tube Wall Thickness | 0.035 in. /0.89 mm |
| Tube Length | 0.30 in. /7.6 mm |
| Handle Type | Round Handle |
| Temperature Rating | -10℉ to 150℉ (- 23℃ to 65℃) |
| Working Pressure Rating | Max 3000 PSIG (207 bar) |
| Testing | Gas Pressure Test |
| Cleaning Process | Cleaning and packaging for ultrahigh- purity products, apply to all Hikelok ultrahigh- purity valves and fitting, no need to add any suffixes to ordering number (CP-03) |
