Short description
Stainless Steel PV1 Series Plug Valve, 0.1 Cv, 3 mm Hikelok Tube Fitting Part #: PV1-M3-V02-316
PT Jacesti Antamani — official sole agent of Hikelok for Indonesia.
Product details
| Attribute | Plug Valves |
|---|---|
| Body Material | 316 Stainless Steel |
| Connection 1 Size | 3 mm |
| Connection 1 Type | Hikelok® Tube Fitting |
| Connection 2 Size | 3 mm |
| Connection 2 Type | Hikelok® Tube Fitting |
| Seat Material | Fluorocarbon FKM |
| CV Maximum | 0.1 |
| Orifice | 0.093 in. /2.4 mm |
| Handle Color | Black |
| Flow Pattern | 2-Way, Straight |
| Temperature Rating | -10℉ to 400℉(-23℃ to 204℃) |
| Working Pressure Rating | Max 3000 PSIG (207 bar) |
| Testing | Gas Pressure Test |
| Cleaning Process | Standard Cleaning and Packaging (CP-01) |
